Analys 2016net
NDIR-Analyser Analys 2016net for the measurement of toxic or explosive gas or oxygen
Analyser with up to 16 measuring points for the measurement of toxic or explosive gas or oxygen with a pump-bypass system. Indication of the gas concentration and the alarm status. To actuate the pre sucktion pump block. To actuate the solenoid valve block with separately pre suck and sample drawing. The system can be adapted to all customized requirements, simply with the password protected menu structure. The configuration of the alarm organization is very simply realized with the integrated alarm matrix.
Technical data:
Type of device: Analys 2016net
Power supply: 24V DC
Power consumption: 25W
Operating temperature: -20°C to +50°C (short time 60°C)
Analog output: 1 x 4-20 mA (max. 250 ohms)
Digital output: 4 Logic signal for Alarm 1-4
1 Logic signal for Sensor fault
1 Logic signal for calibration mode*
1 Logic signal for calibration status
1 Logic signal for maintenance alarm
to activate the solenoid valve unit
to activate the presuction pump block
Network: TCP/IP RS232C CAN Bus (in preparation)
Remote control: with TCP/IP
Data pick up: with FTP
Data recorder: for max. 4000 events
Temperature recorder: for max. 4000 events
*Note dew point of sampling
Technical data IR-Sensor:
Gas: Methane CH4 (Ex)
Measuring procedure: ND-Infrared Detector
Measuring range: 0-100% LEL (0-5 Vol.%)
Reaction time (T90): < 10 sec.
Accuracy: +- 2% FS
Stability: < +- 1%/month
Zero-Drift: < +- 1%/month
Humidity relativ: 99% H.rel.
Warm up time: 1 h
Electrical connections:
Power supply: 3 pole Plug
Interrface: 2 x 37 pole Plug
RS232C: 1 x 9 pole Plug
CAN: 1 x 9 pole Plug
TCP/IP: RJ45
Remote control: with web interface
Pneumatic connections:
Push plug-in: 2 x 6 mm
Dimensions:
Type of device: 19 inch rack version
Painting: Powder coating RAL 7035/5002
IP Rating: IP30
Dimensions: 243 x 223 x 129 mm (3HE/42TE)
Wight: 2.6 kg
Item number: 00-92-35200-A
